TECHNICAL PARAMETER
Rated power（kw）：80
Rated speed（rpm）：1200
Rated torque（N.m）：636
Rated voltage（v）：380
Rated DC bus voltage（v）：540
Minimum bus voltage for full power operation（v）：400
Maximum efficiency（%）：≥96.5%
Efficient zone（%）：≥90.0%
Insulation level：H
IP Grade：IP68
Cooling mode：Liquid cooling
Work noise(dB)：≤80
Outer diameter of water nozzle（mm）：25
Peak power（kw）:180
Peak speed（rpm）:3000
Peak torque（N.m）:1500
Rated current（Arms）:150
Maximum current（Arms）:380
Maximum speed corresponds to no-load Counter-Electromotive force（v）:710
Peak power duration（s）:60
Peak torque duration（s）:30
Overall dimensions（mm）：φ405*330
Weight（kg）:≤150
Cooling water inlet temperature(℃):≤65
Cooling water flow rate(L/min):≥15.0
Operation Temperature Range(℃):-40/+85
SCOPE OF APPLICATION
City Bus 8.5-12m，Commuter Bus 8.2-11m
