Ürün açıklaması
TECHNICAL PARAMETER
Rated power（kw）：60
Rated speed（rpm）：1500
Rated torque（N.m）：382
Rated voltage（v）：253
Rated DC bus voltage（v）：385
Minimum bus voltage for full power operation（v）：358
Maximum efficiency（%）：≥95.0%
Efficient zone（%）：≥90.0%
Insulation level：H
IP Grade：IP68
Cooling mode：Liquid cooling
Work noise(dB)：≤78
Outer diameter of water nozzle（mm）：25
Peak power（kw）:110
Peak speed（rpm）:4500
Peak torque（N.m）:950
Rated current（Arms）:135
Maximum current（Arms）:380
Maximum speed corresponds to no-load Counter-Electromotive force（v）:608
Peak power duration（s）:60
Peak torque duration（s）:30
Overall dimensions（mm）：φ326*538
Weight（kg）:≤127
Cooling water inlet temperature(℃):≤65
Cooling water flow rate(L/min):≥15.0
Operation Temperature Range(℃):-40/+85
SCOPE OF APPLICATION
Light truck、Light bus、Auxiliary drive motor for sanitation vehicle&Supporting 600A main drive motor
