Onboard Internet 5G WiFi Router with SIM Card Slot

Onboard Internet  5G WiFi Router with SIM Card Slot

CPU: MIPS Dual core 880MHz

RAM: 4Gbit

FLASH storage: 256Mbit

Mobile module

5G Sub-6Ghz SA/NSA 2/2.6Gbps DL (4x4 MIMO), 1Gbps/650 Mbps UL

(2x2); 4G (LTE) – LTE Cat 12 600Mbps DL, 150Mbps UL;3G – 44.2

Mbps DL, 11Mbps UL;

Frequency

5G NR NSA: n1/ n3/ n7/ n28/ n38/ n40/ n41/ n77/ n78

5G NR SA: n1/ n3/ n5/ n7/ n8/ n20/ n28/ n38/ n40/ n41/ n66/

n77/ n78

4G (LTE-FDD): B1/ B2/ B3/ B4/ B5/ B7/ B8/ B20/ B28/ B66

4G (LTE-TDD): B38/ B40/ B41

3G: B1/ B2/ B5/ B8

Region EMEA,APISC,AMLAT

Status Signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP Bytes

sent/received, connected band, IMSI, ICCID.

APN Auto APN

WIRELESS

Wireless mode 802.11b/g/n/ac/ax (WiFi 6) with data transmission rates of up

to 1700 Mbps (Dual Band, MU-MIMO),

WiFi security WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP; AES

CCMP, TKIP, Auto Cipher modes,

ESSID ESSID stealth mode

WiFi users Up to 120 simultaneous connections

WiFi Antennas Built-in WIFI6 antenna protected by patented technology

Wireless Hotspot Captive portal (Hotspot), internal/external Radius server,

built in customizable landing page
